PhoneAire 500 Wireless Telephone Entry System

A residential and commercial architectural grade unit with maximum appeal, ruggedness, and expandability.


RE-2 Flush Mount Telephone Entry System

Refining the Look of Telephone entry systems.
Redefining the capabilities of access control.

All this for only $1,286.99


Description:


  • The American Access Systems, Inc PhoneAire is a fully digital, wireless telephone entry system. The transmitter is constructed using a heavy gauge, powder coated enclosure and stainless steel faceplate that mounts directly to a pedestal or can be surface mounted. The PhoneAire’s receiver is mounted in a standard rain-tight enclosure with a baked enamel finish and mounts directly to the side of the home or main building.

    The PhoneAire allows the user to conveniently screen entrants from the home or office. When a guest presses the call button a unique ring cadence alerts someone that a guest is present at the gate. Communication is made from any phone on that line and access is granted by pressing the ** on the telephone’s keypad. The gate can also be opened from inside the building without someone present at the gate. This system features call forwarding, call waiting, “one-shot” code, sleep mode, full programming capability from the interior telephone, a manual override providing phone switching in the event of damage to the telephone entry unit and an optional pinhole camera (hardwired) for additional security. For pre-authorized entry, a fully programmable 500 code keypad is provided. The PhoneAire telephone entry is a “No Phone Line” telephone entry system, allowing you to use your existing telephone line without creating an addition to the phone bill.

Phoneaire

Features:


  • 500 access code capacity
  • • Up to 3500 ft. line of sight communication range
    • Personal Master code
    • Call forwarding
    • Call waiting
    • Latch code
    • Sleep mode
    • Programmable “One -Shot” code
    • Fully programmable from telephone
    • 2 relays
    • Adjustable volume: microphone, speaker & phone tone
    • Event Input
    • Night Light “60 second on” capability
    • Unique ring cadence
    • By-pass switch included



This revolutionary new phone system will redefine the way residential telephone systems are thought of. Simply install one unit at the gate and a receiver on the house by the phone box. That's it... you're done! No long distance wire runs needed. Just like the PhoneLink system, the AAS PhoneAire system will be 100% solar compatible. That way, there is no need to run any wires between the house and the gate. Simple, efficient and dependable... just what you expect from American Access Systems, Inc - Your Partner In Access Control!




Technical Spec:



Transmitter Unit (16-1055t)
Receiver Unit (16-1055r )
Input: 12 VAC or VDC AC (transformer included)
Output: n/o or n/c contact 1-99 second
Operating temperature: -15 to 175 Fahrenheit
Dimensions: 7 3/8" H x 7 3/8" W x 5" D
160mA continous power usage
Ship weight/16-1055r & 16-1055t: 9 lbs.
Up to 3500 ft. line of sight communication range
Less than 45 mA draw (without nightlight)


Input: 12 VAC or VDC AC (transformer included)
Operating temperature: -15 to 175 Fahrenheit
Dimensions: 7 3/8" H x 7 3/8" W x 5" D






Relay Specs

DC Load
AC Load
Contact Rating
2A @ 30V
.5A @ 125V
Max. switching voltage
125V
125V
Max. carrying current
2A
2A
Max. switching power
60W
62.5VA














a

PhoneAire Discounted Pricing:

Item #
Description
List Price
Our Price
Online Ordering
Phoneaire
16-1055
PhoneAire 500-Code Wireless Telephone Entry System
(Includes 2 Transformers)
$1,286.99
$1,286.99
Discontinued

Accessories & Replacements:

PhoneAire - Transmitter Unit (transformer included)
16-1055t
PhoneAire - Transmitter Unit Only
(transformer included)
$713.21
Add to cart to see lower price
Discontinued
PhoneAire - Receiver Unit (transformer included)
16-1055r
PhoneAire - Receiver Unit Only
(transformer included)
$713.21
Add to cart to see lower price
Discontinued
PhoneAire - Antenna Extention (Optional)
16-10ext
PhoneAire - Antenna Extention
(Optional)
$76.46
Add to cart to see lower price
Discontinued



The American Access Systems, Inc PhoneAire is a fully digital, wireless telephone entry
system. The transmitter is constructed using a heavy gauge, powder coated enclosure and
stainless steel faceplate that mounts directly to a pedestal or can be surface mounted. The
PhoneAire’s receiver is mounted in a standard rain-tight enclosure with a baked enamel
finish and mounts directly to the side of the home or main building.
The PhoneAire allows the user to conveniently screen entrants from the home or office
using “AAS - Push To Talk” communication. When a guest presses the call button a unique
ring cadence alerts someone that a guest is present at the gate. Communication is made
from any phone on that line and access is granted by pressing the ** on the telephone’s
keypad. The gate can also be opened from inside the building without someone present at
the gate.


This system features call forwarding, call waiting, “one-shot” code, sleep mode, full
programming capability from the interior telephone, a manual override providing phone
switching in the event of damage to the telephone entry unit. For pre-authorized entry, a
fully programmable 500 code keypad is provided.
The PhoneAire telephone entry is a “No Phone Line” telephone entry system, allowing you
to use your existing telephone line without creating an addition to the phone bill.
